SCM6010 & CAN6000 6U OpenVPX SSD Storage
Mercury Systems
The EnsembleSeries™ SCM6010 is a 6U OpenVPX SSD plug-in storage module with PCIe switching and removable canister (CAN6000), offering low-latency storage that performs like memory.
Technical specifications
- Storage
- Up to 24TB
- PCIe Lanes
- 48 x PCIe Gen3
- Form Factor
- 6U OpenVPX
- Environmental Protection
- MOTS+
- System Management
- VITA 46.11
- Compliance
- VPX-REDI and VITA 65
- Input voltages
- 12V payload power
- Input voltages (2)
- 3.3V AUX management power
- OpenVPX Slot Profile
- VITA 65 slot profile: VPX6-PER-16.10-15
- VITA 65 module profile
- MOD6-PER-16-12.3.5-n
- Mass
- 48.1 kg
About
The SCM6010 storage drives are an industry first, featuring removable storage canisters that allow users to easily replace storage for rapid mission updates, removal of sensitive material, and technological refreshes. Designed for deployment anywhere, these wideband, low-latency storage modules are available with modified-off-the-shelf-plus (MOTS+) packaging technology, providing extreme environmental protection. To meet the vast memory and storage demands critical for remote deployment of contemporary AI, electronic warfare, electro-optical/infrared, and other big processing, image-intensive applications, the SCM6010 modules access their M.2 NVMe drives via an efficient PCIe architecture, performing more like memory than traditional storage. Key features include up to 24TB of high-speed storage, 48 x PCIe Gen3 low-latency, high-bandwidth read/write lanes, removable storage canisters, advanced VITA 46.11 system management & monitoring, VPX-REDI and VITA 65 compliance.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
