SFM6126 6U OpenVPX Network Switch Board
Mercury Systems
The EnsembleSeries™ SFM6126 switch is a critical building block for composable, embedded data center architectures, enabling efficient, low-latency PCIe switching for AI, sensor fusion, and big data processing applications.
Typed specifications5 values
Discloses 2 of 11 fields engineers filter by in this category (category median 4).
- Envelope (L×W×H)
- 160mm x 233.33mm datasheet p.3
- Supply voltage
- 3.3 V management power · datasheet p.3 12 V payload power
- Data interface
- Ethernet datasheet p.1 other PCIe Gen3
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier8 lines, in the manufacturer's own wording
- PCIe Switching
- Full Gen3 high-bandwidth
- Control Plane Switching
- 16x ports of 10GbE
- I/O Sites
- Dual XMC
- System Management
- VITA 46.11
- Fiber Optic Interface
- VITA 66 (available)
- Environmental Protection
- MOTS+
- OpenVPX Slot Profile
- SLT6-SWH-16U16F-10.4.5
- OpenVPX Module Profile
- MOD6-SWH-16U16F-12.4.5-X*
About
The SFM6126 6U OpenVPX Network Switch Board from Mercury Systems provides efficient, low-latency PCIe switching, making it a key component for forming composable, embedded data center architectures. It is designed for artificial intelligence (AI), sensor fusion, and other big data processing applications. The board features onboard XMC I/O sites and mezzanine switching capabilities, facilitating direct, low-latency PCIe data distribution to CPU, GPU, FPGA, and storage devices, bypassing traditional store-and-forward approaches in CPU memory. When integrated with other EnsembleSeries OpenVPX modules, such as Intel® Xeon® Scalable-powered multifunction modules and powerful GPU co-processors, the SFM6126 delivers rugged, high-performance embedded edge computing for aerospace and defense platforms operating in extreme environments. Key features include full Gen3 PCIe high-bandwidth switching, 16x ports of 10GbE control plane switching, I/O distribution for PCIe data or expansion/sensor planes, transparent or non-transparent port-by-port bridging, dual XMC I/O sites, VITA 46.11 system management, and optional VITA 66 fiber optic interface. It also offers MOTS+ extreme environmental protection and is designed, built, coded, and supported from trusted DMEA facilities.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
