spaceware™ Hall Effect Thruster
Exotrail
spaceware™ is a next-generation Hall Effect thruster designed for versatility and power, featuring a modular architecture for easy integration into diverse satellite platforms and delivering industry-leading thrust for electric propulsion.
Key figurescomparable across the catalogue
- Power
- 60 W
- Thrust
- 0.003 N
- Total impulse
- 6,000 N·s
- Design life
- 7 years
Normalised to common units so this product can be compared with others in its category. The supplier's own wording is below.
As published by the supplier
- Thrust
- 2.5 mN
- Power
- 60 W
- Total Impulse
- Up to 6 kN.s
- ON/OFF cycles
- 3,000 cycles
- Lifetime
- 5 years In-Orbit
- Propellant type
- Xenon
- Control Interface
- CAN/RS422/RS485
- Power interface
- 16V or 28V unregulated
- Thrust
- 7 mN
- Power
- 150 W
- Total Impulse
- Up to 60 kN.s
- ON/OFF cycles
- 6,000 cycles
- Lifetime
- 5 years In-Orbit
- Propellant type
- Xenon
- Control Interface
- CAN/RS422/RS485
- Power interface
- 28V unregulated
- Thrust
- 12–32 mN
- Power
- 300–600 W
- Total Impulse
- Up to 450 kN.s
- ON/OFF cycles
- 11,000 cycles
- Lifetime
- 7 years In-Orbit
- Propellant type
- Xenon/Krypton
- Control Interface
- CAN/RS422/RS485
- Power interface
- 28V unregulated
About
spaceware™ is a next-generation Hall Effect thruster, purpose-built for missions demanding both versatility and power. Its highly modular architecture enables easier integration into diverse satellite platforms, while delivering industry-leading thrust for electric propulsion. The product line includes three configurations: spaceware™ – nano, a 60W-class system for 10 to 80kg platforms, offering a compact, light, and flexible solution for cubesats; spaceware™ – micro, a 150W-class system providing high thrust and maneuver capabilities for microsats, with cluster configurations for increased thrust, lifetime, and reliability; and spaceware™ – mini, a 400W-class system targeting multi-propellant capabilities (Xenon & Krypton) for small satellite constellations. The technology miniaturizes Hall Effect Thruster technology to bring low thrust propulsion to the smallsat market.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
