6U CubeSat Platform SXC6 ADC AS TFF
SPUTNIX
6U CubeSat platform with 3-axis ADCS. Up to 12 kg S/C mass, 78 Wh battery, 35 W solar panels, UHF transceiver with deployable antennas. Reaction wheels and sun orientation included.
Typed specifications6 values
Discloses 1 of 7 fields engineers filter by in this category (category median 3).
- Mass
- 12 kg product page
- Envelope (L×W×H)
- 118.6 × 228.6 × 366 mm stowed · product page
- Power consumption
- 35 W product page
- Form factor
- 6U product page
- Battery capacity
- 78 Wh product page
- Max satellite wet mass
- 12 kg Max s/c mass · product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier7 lines, in the manufacturer's own wording
- Form factor
- 6U CubeSat
- Dimensions (stowed)
- 118.6 × 228.6 × 366 mm
- Max s/c mass
- 12 kg
- Battery capacity
- 78 Wh
- Peak solar power
- 35 W
- ADCS pointing (sunlit)
- up to 1°
- UHF frequency
- 435–438 MHz
About
SPUTNIX SXC6-ADC is the full-featured configuration of the SXC6 nanosatellite platform with 3-axis attitude determination and control. Includes reaction wheels for precision pointing, sun orientation capability, and redundant UHF communications. Ready for payload integration per SXC6 ICD.
Subsystems included
- Redundant PSS with battery and deployable solar panels
- Redundant UHF transceiver with patch and deployable dipole antennas
- Redundant electromagnetic detumbling system
- Redundant ADCS control unit with sensor suite
- Partially redundant reaction wheels
- Sun sensor set
| Parameter | Value |
|---|---|
| Form factor | 6U CubeSat |
| Dimensions (stowed) | 118.6 × 228.6 × 366 mm |
| Dimensions (deployed) | 118.6 × 228.6 × 820 mm |
| Mass (w/o payload) | ≤5 kg |
| Max S/C mass | ≤12 kg |
| Battery capacity | 78 Wh (Li-Ion 2S+2P) |
| Peak solar panel power | ≥35 W |
| UHF frequency | 435–438 MHz |
| UHF transmit power | ≥30 dBm |
| Data rate | 4800–57600 bps |
| ADCS pointing accuracy (sunlit) | up to 1° |
| ADCS pointing stability | up to 0.1° |
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
