Antenna-feeder system of global navigation satellite systems
SPUTNIX
A passive printed L1-band antenna (AFS-GNSS) for receiving GNSS positioning signals aboard a spacecraft.
Typed specifications5 values
Discloses 4 of 10 fields engineers filter by in this category (category median 3).
- Mass
- 61 g product page
- Frequency range
- 1 559–1 607 MHz product page
- Envelope (L×W×H)
- 68 x 68 x 15 mm product page
- Polarization
- RHCP product page
- Antenna type
- patch product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier9 lines, in the manufacturer's own wording
- Antenna type
- Printed
- Operating frequency range
- 1559-1607 MHz
- Gain
- at least 5.5 dB
- Standing wave voltage coefficient
- no more than 1.5
- Type of polarization
- Circular, RHCP
- Normal ellipticity coefficient
- no more than 1.7 dB
- Width of radiation pattern at minus 3 db level
- at least 84 degrees
- Dimensions
- 68 x 68 x 15 mm
- Mass
- 61 g
About
AFS-GNSS is a passive printed antenna for receiving GNSS signals in the L1 band, used together with the satellite navigation equipment/GNSS receiver.
