RSA-2500B
AVCOM of Virginia
The RSA-2500B is a 1RU rack-mount spectrum analyzer designed for remote monitoring and control in SATCOM facilities, offering flexibility with up to 6 inputs and various configuration options.
Key figurescomparable across the catalogue
- Mass
- 3.18 kg
- Power
- 9 W
Normalised to common units so this product can be compared with others in its category. The supplier's own wording is below.
As published by the supplier
- Up to 6 inputs
- in 1RU Enclosure
- Easily integrated
- into OEM Applications
- Full remote monitor and control
- via IP; Ethernet
- Gui software included
- License-free
- Frequency range
- 5 MHz – 2300 MHz
- Span width
- Up to 1300 MHz (Dependent on Center Frequency)
- Resolution bandwidth
- 10 kHz, 100 kHz, 300 kHz, 1 MHz
- RF sensitivity
- Greater than -85 dBm Typical
- Reference levels
- Selectable -10 dBm to -50 dBm in 5 dBm increments
- Scale
- 5 dB/Div & 2 dB/Div
- Dynamic range
- 50 dBm GUI window
- Amplitude accuracy
- ± 1 dB typical
- Frequency accuracy
- ± 1 kHz typical
- Max RF input
- 25 VDC MAX (DC Blocked), +30 dBm (1 W)
- Input impedance
- 50 Ω
- Amplitude range
- 0 dBm to -85 dBm (standard) 0 dBm to -105 dBm (preamp option) +10 dBm to -65 dBm (attenuator option)
- Input connector
- Input 1: BNC standard. F, TNC, SMA, N available. Inputs 2-6: Optional
- Operating temperature range
- 10°C to +60°C
- Physical dimensions
- 19” W x 18” L x 1.75” H
- Mass
- 7lbs
- Power requirements
- +15 VDC/9 W; Universal AC-DC Converter Included with IEC Type 1 plug
About
The RSA-2500B is a versatile spectrum analyzer housed in a 1RU chassis, offering total flexibility for integrators in SATCOM facilities. It can support up to 6 inputs and allows for simultaneous monitoring of up to 16 different RSA units from three locations via IP using the AVCOM EVO GUI software. Configuration options include a choice of input connectors, LNB power, preamps for low-level signals, attenuators for higher-level signals, and down converters for higher input frequencies. The RSA-2500B is designed for the measurement and analysis of communications and broadcast carriers, including link, L-Band carriers, IF, and 10MHz reference signals. It provides excellent uplink, downlink frequency and amplitude accuracy, with resolution bandwidth (RBW) selection from 10kHz to 1MHz, which is crucial for viewing and monitoring Telemetry, Tracking, Command Systems (TT&C), data carriers in satellite systems, spread spectrum, and Wi-Fi. Variable reference levels (RL) from -10dB to -50dB enable the viewing of both small and large signals. The unit features full remote monitoring and control via IP (Ethernet) and includes license-free GUI software. It also offers options for extended amplitude range, frequency bands, and LNB power. The RSA-2500B can be monitored and controlled using the Avcom Remote Control Software EVO-GUI via USB or Ethernet, with an intuitive user interface that can display up to sixteen windows simultaneously and runs on Windows OS.
