High Motor Torque Momentum and Reaction Wheels
Collins Aerospace
Collins Aerospace offers Teldix space wheels with integrated wheel drive electronics, providing angular momentum storage from 0.04 to 68 Nms for spacecraft weighing 30 kg to 7,000 kg.
Typed specifications4 values
Discloses 3 of 10 fields engineers filter by in this category (category median 5).
- Mass
- 7 150 g as published, mode unspecified · vendor page (catalogue a
- Angular momentum storage
- 68 N·m·s as published, mode unspecified · vendor page (catalogue a
- Power consumption
- 20 W as published, mode unspecified · vendor page (catalogue a
- Design lifetime
- 15 years as published, mode unspecified · vendor page (catalogue a
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier6 lines, in the manufacturer's own wording
- Angular momentum storage capacity
- 0.04 to 68 Nms
- Integrated wheel drive electronics
- 14 to 68 Nms
- Accommodates spacecraft weighing
- 30 kg to 7,000 kg
- Suitable for satellites weighing
- 1,500 to 5,000 kg
- Combined in-orbit operational time
- More than 7,300 years
- Lifetime design
- More than 15 years
About
Collins Aerospace’s Teldix space wheels are high motor torque momentum and reaction wheels that can be chosen with integrated wheel drive electronics, offering angular momentum storage capacities ranging from 0.04 to 68 Nms. These wheels are designed to accommodate the attitude control system requirements for spacecraft weighing between 30 kg and 7,000 kg. The product line boasts more than 40 years of experience in space wheel technology and over 7,300 years of combined in-orbit operational time. Key features include optimization for power/loss torque and volume/mass, hermetically sealed construction, and a modular configuration allowing for fast adaptation to customer requirements. The wheels incorporate space-qualified subsystems, including the rotor, motor, bearing unit, and electronics. They are available in a broad spectrum of types, suitable for satellites weighing 1,500 to 5,000 kg, and are designed for high reliability through heritage, with a lifetime design exceeding 15 years. They can be used interchangeably as momentum or reaction wheels.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
