Teldix High Motor Torque Momentum and Reaction Wheels
Collins Aerospace
Collins Aerospace's Teldix space wheels are high motor torque momentum and reaction wheels with integrated wheel drive electronics, used in spacecraft attitude control systems.
Typed specifications49 values
Discloses 6 of 10 fields engineers filter by in this category (category median 5).
- Mass
- 8 900 g max · datasheet p.2 6 300 g max · RSI 18-220/45 | 8 500 g max · RSI 30-280/30 | 8 900 g max · RSI 68-170/60
- Envelope (L×W×H)
- 347 mm (Diameter) x 124 mm (Height) datasheet p.2
- Angular momentum storage
- 68 N·m·s at nominal speed · datasheet p.2 18 N·m·s RSI 18-220/45, at nominal speed | 30 N·m·s RSI 30-280/30, at nominal speed | 68 N·m·s RSI 68-170/60, at nominal speed
- Max torque
- 170 mN·m at nominal speed · datasheet p.2 220 mN·m RSI 18-220/45, motor torque at nominal speed (+/- 220 mNm) | 280 mN·m RSI 30-280/30, motor torque at nominal speed (+/- 280 mNm) | 170 mN·m RSI 68-170/60, motor torque at nominal speed (+/- 170 mNm)
- Speed range
- -6 000 rpm min · datasheet p.2 6 000 rpm max | -4 500–4 500 rpm RSI 18-220/45 | -3 000–3 000 rpm RSI 30-280/30 | -6 000–6 000 rpm RSI 68-170/60
- Supply voltage
- 98 V min · datasheet p.2 98 V min · RSI 18-220/45 | 98 V min · RSI 30-280/30 | 98 V min · RSI 68-170/60 | 102 V max +4
- Power consumption
- 150 W max · Maximum torque at nominal speed · datasheet p.2 150 W max · Maximum torque at nominal speed (RSI 18-220/45) | 150 W max · Maximum torque at nominal speed (RSI 30-280/30) | 150 W max · Maximum torque at nominal speed (RSI 68-170/60) | 20 W max · Steady state at nominal speed +3
- Operating temperature
- -20 °C min · datasheet p.2 70 °C max | -20–70 °C
- Design lifetime
- 15 years >, in orbit · datasheet p.2 15 years in orbit | 15 years min · in orbit
- Peak power
- 150 W max · maximum torque at nominal speed · datasheet p.2
- Survival temperature
- -40 °C min · datasheet p.2 70 °C max | -40–70 °C
- Satellite class
- smallsat 100-500 kg datasheet p.1 large >500 kg for satellites weighing 1,500 - 5,000 kg | large >500 kg
- Drive electronics
- integrated with integrated Wheel Drive Electronics · datasheet p.1
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier10 lines, in the manufacturer's own wording
- Wheel drive electronics integration
- 14 to 68 Nms
- Angular momentum storage capacity
- 0.04 to 68 Nms
- Supported spacecraft mass range
- 30 kg to 7,000 kg
- High motor torque variant satellite mass range
- 1,500 to 5,000 kg
- Lifetime design
- More than 15 years
- Combined in-orbit operational time (Teldix space wheels)
- More than 7,300 years
- Space wheel technology experience
- More than 40 years
- Configuration
- Modular, hermetically sealed
- Usable as
- Momentum wheel or reaction wheel
- Space qualified subsystems
- Rotor, motor, bearing unit and electronics
About
Teldix space wheels from Collins Aerospace are momentum and reaction wheels for spacecraft attitude control systems (ADCS), available with integrated wheel drive electronics at 14 to 68 Nms, or as customizable solutions. The wheel family spans an angular momentum storage capacity range between 0.04 and 68 Nms, accommodating spacecraft weighing between 30 kg and 7,000 kg, with a high motor torque variant intended for satellites weighing 1,500 to 5,000 kg. The wheels are usable as either a momentum wheel or a reaction wheel. They are power/loss torque optimized as well as volume/mass optimized, hermetically sealed, and built in a modular configuration allowing fast adaptation to customer requirements. Key subsystems – rotor, motor, bearing unit and electronics – are space qualified, and the product line spans a broad spectrum of different wheel types. Collins Aerospace states more than 40 years of experience in space wheel technology, with Teldix space wheels accumulating more than 7,300 years of combined in-orbit operational time, described as far exceeding competing products. The wheels are designed for high reliability through heritage and a lifetime design of more than 15 years.
Documentation
- SatCatalog_-_Collins_Aerospace_-_RSI_30-280-30_-_Datasheet.pdf PDF source: satcatalog.s3.amazonaws.com ↗
