IRT NX SATCOM System for Iridium Certus
Next-generation Iridium Certus SATCOM system delivering higher data throughput with lower weight and power consumption.
Description
The IRT NX is Collins Aerospace's next-generation Iridium Certus SATCOM system delivering significantly higher data throughput than the IRT-2110/2120 series with lower weight and power consumption. The integrated system supports voice, IP data, FANS, ACARS, ADS-B Out, and passenger connectivity with global, pole-to-pole coverage.
Specifications
| Satellite Network | Iridium Certus (LEO, 66 operational + 9 spare satellites) |
|---|---|
| Frequency Band | L-band |
| Max Downlink | 704 kbps (Iridium Certus 700) |
| Max Uplink | 352 kbps |
| Coverage | Global, pole-to-pole |
| Voice Channels | 2 ATS voice channels |
| Capabilities | FANS, ACARS, ADS-B Out, ALERT, GlobalBeacon, passenger IP data |
| Certifications | EASA retrofit certified 2024; FAA STC eligible |
