GR765 Octa-Core RISC-V/SPARC Rad-Hard SoC
Gaisler
Next-generation rad-hard system-on-chip with 8 RISC-V/SPARC cores, embedded FPGA, and integrated hardware security module.
Technical specifications
- Cores
- Up to 8, RISC-V/SPARC
- Memory interfaces
- DDR2/DDR3/DDR4
- High-speed i/o
- SpaceFibre, WizardLink
- Embedded FPGA
- Radiation-hardened eFPGA, 32k LUTs
- Security
- Isolated HSM SoC, PQC support, hardware root of trust
- Frequency
- 800 MHz
- Package
- FF1760
- Technology
- STM 28 nm FDSOI
- TID
- 50 krad (Si)
- SEL
- >= 60 MeV*cm²/mg @ Tj=+125C
- L2 cache
- 4 MiB
- L1 cache
- 32 KiB
- DMIPS/core
- 2600
- Max accessible memory
- 16 GiB
- SpaceWire
- 12 external interfaces and 4 internal ports
- Ethernet ports
- 6xRGMII or 4xSGMII or 8xQSGMII
- MIL-STD-1553B
- 2x
- CAN FD
- 4x
About
The GR765 is a high-performance radiation-hardened system-on-chip supporting up to 8 cores (RISC-V/SPARC), DDR2/DDR3/DDR4 memory interfaces, and integrated SpaceFibre and WizardLink high-speed communication interfaces. The GR765 includes a radiation-hardened embedded FPGA (eFPGA) with 32k LUTs that can interface directly with SpaceFibre/WizardLink for data decimation and in-hardware processing, avoiding the need for TMR or scrubbing. It also integrates an isolated SoC operating as a Hardware Security Module (HSM), providing authenticated boot, unique device identification, hardware root of trust, secure message signing/verification/encryption, key management, integrated crypto accelerators, and support for Post-Quantum Cryptography (PQC) algorithms.
