ST 6100
Orbcomm
The ST 6100 is a comprehensive satellite IoT terminal designed for reliable and cost-effective satellite IoT connectivity in remote locations.
Typed specifications27 values
Discloses 6 of 13 fields engineers filter by in this category (category median 3).
- Frequency band
- L IsatData Pro RX · datasheet p.2 L IsatData Pro TX | L OGx RX | L OGx TX | L Rx 1525.0-1559.0 MHz / Tx 1626.5-1660.5 MHz
- Frequency range
- 1 525–1 559 MHz IsatData Pro RX · datasheet p.2 1 626.5–1 660.5 MHz IsatData Pro TX | 1 525–1 559 MHz OGx RX | 1 626.5–1 660.5 MHz OGx TX | 1 525–1 559 MHz Rx (OGx / IsatData Pro) +1
- Envelope (L×W×H)
- 12.6 cm x 12.6 cm x 4.9 cm datasheet p.2
- RX sensitivity
- -148 dBm GPS/Glonass/Beidou/Galileo Acquisition · datasheet p.2 -163 dBm GPS/Glonass/Beidou/Galileo Tracking
- Supply voltage
- 9–32 V datasheet p.2
- Data interface
- RS-232 datasheet p.2 GPIO 4 analog or digital in/out | RS-485
- Operating temperature
- -40–85 °C datasheet p.2
- Function
- transceiver two-way satellite terminal · datasheet p.1
- Link use
- IoT / M2M uplink datasheet p.1 ground terminal
- Link protocol
- proprietary OGx or IsatData Pro satellite services · datasheet p.2
- Encryption
- AES-256 AES 256 encryption-capable · datasheet p.2
- Satellite network
- Inmarsat Inmarsat Type Approval · datasheet p.2 other OGx or IsatData Pro satellite service
- EIRP
- 7 dBW max · <7.0 dBW · datasheet p.2
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier15 lines, in the manufacturer's own wording
- Maximum message size
- 1 MB
- Typical latency
- <15 sec
- Elevation angle
- 0° to +90°
- Frequency
- Rx 1525.0 to 1559.0 MHz
- EIRP
- <7.0 dBW
- Dimensions
- 12.6 cm x 12.6 cm x 4.9 cm
- Input voltage
- 9 to 32 V
- Power consumption
- 65 mA
- Lua Code RAM
- 4 MB
- Lua Code NVM
- 8 MB
- Operating temperature
- -40°C to +85°C
- Dust and water ingress
- IP67
- Acquisition time
- 1 second
- Accuracy
- 2.0 m CEP
- Sensitivity
- -148 dBm
About
The ST 6100 is a satellite IoT terminal that enables remote IoT use cases across various verticals such as utilities, energy, and oil and gas. It provides reliable and cost-effective satellite IoT connectivity, allowing customers to keep their assets connected even in the world’s most remote locations. The terminal features improved coverage with integrated antennas that offer enhanced low elevation angle performance, supporting both terrestrial and maritime applications. It is designed for easy integration, offering development, testing, and production environments, comprehensive documentation, code samples, pre-built terminal applications, and technical support to accelerate time to market. The ST 6100 is versatile, capable of handling complex deployments through configurable applications and custom scripts, and simplifies device management with over-the-air update support.
