TensorCMG-10m-S
Tensor Tech
Variable-speed, single-gimbal Control Moment Gyroscope for CubeSats up to 16U and nanosatellites up to 30 kg — skew-mount version.
Key figurescomparable across the catalogue
- Mass
- 0.28 kg
- Power
- 1.92 W
- Largest dimension
- 56 mm
Normalised to common units so this product can be compared with others in its category. The supplier's own wording is below.
As published by the supplier
- Dimensions
- 54 x 49 x 56 mm3
- Gimbal axis angular range
- Unlimited
- Power
- 1.92 W
- Mass
- 280 g
- Gimbal maneuver
- > 30 million
- Interface
- RS-485
- Momentum
- 13 mNms on x,y-axis
- Rotor imbalance
- ISO 1940 G0.4
- Radiation hardness
- > 24 krad(Si) on electronics
- Torque (Acceleration)
- 1 mNm
- Torque (Gyroscopic)
- 15 ~ 100 mNm
- Supply voltage
- 6 ~ 14 V
About
The TensorCMG Series is a variable-speed, single-gimbal CMG driven by spherical motor technology. This spherical motor design reduces weight, volume, and power consumption (SWaP). An autonomous torque calculation algorithm is integrated on the control board, enabling multi-axis torque output through simple commands. The TensorCMG-10m is designed for CubeSats up to 16U and nanosatellites up to 30 kg with flight heritage since 2022.
Features: torque-to-power ratio optimization; form factor fits tuna-can standard; soft/hard error fault detection; jitter (micro-vibration) ISO1940 G0.4 @ 8000 rpm; magnetic leakage flux shielded with Ni-iron alloy.
TensorCMG-10m-S is the Skew-Angle Integration Version, pre-configured with a fixed skew angle and featuring a discrete, separately-mounted driving module (External Driving Module) for flexible integration — supports a 53-degree skew angle for pyramid cluster configurations. Available in integrated and discrete versions, with vertical and skew mount configurations and custom or purchasable adapters.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
