ASTROFEIN ACM Magnetometer
EXA (Astro-und Feinwerktechnik)
The ASTROFEIN ACM Magnetometer is a high-precision, space-qualified magnetometer designed for attitude control in small and larger satellites, offering an optimal balance of low mass, size, data quality, and power consumption.
Typed specifications12 values
Discloses 5 of 11 fields engineers filter by in this category (category median 8).
- Mass
- 280 g max · without connector · datasheet p.2
- Measurement range
- 60 µT max · up to 140000 nT on request · datasheet p.2
- Envelope (L×W×H)
- 138 mm x 55 mm x 39 mm datasheet p.2
- Resolution
- 0.1 nT datasheet p.2
- Noise density
- 0.05 nT/√Hz max · 60 000 nT · datasheet p.2
- Supply voltage
- 16–40 V datasheet p.2
- Power consumption
- 1 W max · 24 V, Earth field · datasheet p.2 1.2 W max · 24 V, Full range
- Data interface
- RS-485 others on request · datasheet p.2
- Operating temperature
- -20–50 °C datasheet p.2
- Design lifetime
- 7 years datasheet p.2
- Survival temperature
- -30–60 °C datasheet p.2
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier14 lines, in the manufacturer's own wording
- Range
- ±60 000 nT (up to 140 000 nT on request)
- Resolution
- 100 pT/LSB
- Noise
- 50 pT/ √Hz@60 000 nT
- Linearity
- 0.025%
- Mass
- < 280 g
- Dimensions (without connector)
- 138 mm x 55 mm x 39 mm
- Supply voltage
- 18 V to 36 V
- Power consumption earth field
- < 1.0 W @ 24 V
- Power consumption full range
- < 1.2 W @ 24 V
- Data interfaces
- RS485 (others on request)
- Operation temperature range
- -20°C to +50°C
- Non-operation temperature range
- -30°C to +60°C
- Design lifetime
- 7 years
- Storage time
- 2 years
About
The ASTROFEIN ACM Magnetometer is a high-precision device developed in cooperation with Magson GmbH, specifically designed for attitude control in both small and larger satellites. It offers an optimal balance between low mass/size, high data quality, and efficient power consumption. The electronics are fully Mil/space qualified, and all components are available as radiation hard or radiation tolerant. Key features include field calculation with fully calibrated data output, two different measurement modes, and firmware upload capability. The electronics and sensor are qualified according to vibration specifications for Ariane, Delta, and Soyuz launchers, ensuring robustness for space environments. It operates within a range of ±60,000 nT (up to 140,000 nT on request) with a resolution of 100 pT/LSB and a linearity of 0.025%. The device has a design lifetime of 7 years and a storage time of 2 years.
