Model 4460 Portable Digital RF/IF Receiver
GDP Space Systems
The Model 4460 is a portable, lightweight digital RF/IF receiver designed for telemetry signals, featuring adaptive equalization, LDPC support, and multiple RF bands for downlink processing.
Typed specifications74 values
Discloses 3 of 13 fields engineers filter by in this category (category median 2).
- Frequency bands
- other P-Band (180 to 1100 MHz), optional · datasheet p.2 S RF Frequencies | L RF Frequencies Lower L Band | L RF Frequencies Upper L Band | L Upper L and Lower L Band
- Frequency range
- 550–1 100 MHz P-Band (optional) · datasheet p.1 180–1 100 MHz P-Band option OP4460-81 | 1 427–1 545 MHz RF Frequencies Lower L Band | 2 185–2 485 MHz RF Frequencies S Band | 1 700–1 850 MHz RF Frequencies Upper L Band +4
- Envelope (L×W×H)
- 10.75 x 12 x 1.75 inch chassis datasheet p.1 10.75 x 12 x 1.75 inch chassis
- Data rate
- 20 000 kbps BPSK, optional · datasheet p.1 20 000 kbps PCM/FM & BPSK Bit Synchronizer(s), optional | 20 000 kbps PCM/FM Demodulator, optional | 40 000 kbps QPSK, optional | 40 000 kbps QPSK/SOQPSK Bit Synchronizer(s), optional +10
- Modulation
- BPSK datasheet p.1 UQPSK optional | QPSK | AQPSK optional | OQPSK +9
- Data interface
- TTL datasheet p.1 Ethernet Byte Aligned Data Output, optional | Ethernet Control Interface, Standard | Ethernet Data Output, optional | TTL Data Output, Standard +9
- Operating temperature
- 10–40 °C datasheet p.2 10–40 °C Operational
- Function
- receiver datasheet p.1
- Link use
- ground terminal portable telemetry receiver · datasheet p.1
- Link protocol
- AX.25 datasheet p.0 HDLC optional HDLC/AX.25 data over UDP/IP | AX.25 optional HDLC/AX.25 data over UDP/IP
- Noise figure
- 4 dB max · < 4 dB typ, general specifications page 2 · datasheet p.2 10 dB max · key features, page 1
- Survival temperature
- -40–70 °C datasheet p.2 -40–70 °C Storage
- Duplex
- simplex receiver · datasheet p.1
- Channel coding (FEC)
- convolutional (Viterbi) optional · datasheet p.1 Reed-Solomon optional | LDPC optional
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier20 lines, in the manufacturer's own wording
- Chassis dimensions
- 10.75 x 12 x 1.75 inches high
- RF bands processed
- S Band (2185 MHz to 2485 MHz); Upper L Band (1700 MHz to 1850 MHz); Lower L Band (1427 MHz to 1545 MHz)
- If filters
- Choice of 4 available
- Output ports
- Byte aligned Ethernet (optional), TTL, RS422
- Ethernet transport
- UDP/IP for raw data, optionally HDLC/AX.25mdata
- Output compatibility
- IRIG-106 Chapter 10
- Noise Figure
- < 10 dB
- Dynamic Range
- > 80 dB
- Operating temperature
- 10°C to 40°C
- Storage temperature
- -40°C to 70°C
- Input Impedance
- 50 Ohms
- VSWR
- < 2:1
- IF Acquisition / Tracking Range
- ± 255 kHz
- Loop Bandwidth
- 0.01% to 1% of Bit Rate (Analog PM 2 Hz to 20 kHz)
- PM Demodulator Frequency Response
- 100 Hz to 15 MHz
- PM Demodulator Modulation Index
- 0 to 3.0 Radians
- Locking Threshold
- 6 dB Eb/No
- Bit Synchronizer Bit Rate PCM/FM & BPSK
- 50 bps to 10 Mbps
- Bit Synchronizer Bit Rate QPSK/SOQPSK
- 100 bps to 20 Mbps
- Interface
- Ethernet
About
The Model 4460 Portable Digital RF/IF Receiver is a compact and lightweight unit housed in a 10.75 x 12 x 1.75 inches chassis, powered by a standard laptop power supply or external battery. It integrates an RF Signal Processor, two Demodulators, two Bit Synchronizers, and two Frame Synchronizers (Pattern Detectors) on a single slot 6U VME/PCI card, offering a cost-competitive and flexible solution for various communication link scenarios. Key features include a NEW! 70MHz Test Modulator Output function, Adaptive Equalization (AEQ) to combat multipath distortion and fading for higher fidelity output, and support for Low Density Parity Check (LDPC) codes on the downlink. The receiver processes three RF Bands: S Band (2185 MHz to 2485 MHz), Upper L Band (1700 MHz to 1850 MHz), and Lower L Band (1427 MHz to 1545 MHz), with other frequencies available upon request. Users can choose from four IF filters based on specific requirements. Demodulation and baseband bit synchronization are entirely digital. Signal acquisition involves scanning the IF within a programmed band centered on the carrier frequency, with PM/PSK waveforms also scanned at subcarrier frequencies. After acquisition, synchronized signal tracking maintains continuous lock state validation. The unit includes various FEC decoders and two fully programmable frame synchronizers for pattern detection. Data output options include Byte aligned Ethernet (optional), TTL, or RS422 ports. An optional Ethernet output mode provides frame synchronized byte aligned data, with UDP/IP transport for raw data and optionally HDLC/AX.25mdata. IRIG-106 Chapter 10 compatible output is also available. An encapsulated data and data-quality output can be included to support GDP Best Source Selector products.
