Origami Solar Array
Dcubed
The Dcubed PowerCube is a deployable 100W Origami Solar Array stowed within a 1U form factor, enabling high-power space missions with minimal stowed volume.
Typed specifications3 values
Discloses 2 of 12 fields engineers filter by in this category (category median 3).
- Mass
- 1 200 g product page
- Supply voltage
- 14–28 V product page
- Lead time
- 12 months product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier9 lines, in the manufacturer's own wording
- Short delivery time
- 12 months
- EOL power
- 100 W (5 years lifetime)
- Stowed volume
- 100x100x100 mm (1U)
- Deployed volume
- 110x110x190 mm
- Mass
- 1.2 Kg
- Supply voltage
- 14-28 V
- Redundant actuation
- Yes
- Compliant with the CUBESAT standard
- Yes
- Export control
- ITAR Free
About
The Dcubed PowerCube is a deployable 100W Origami Solar Array designed for high-power space missions. It is stowed within a 1U form factor, making it one of the smallest yet most powerful solar array solutions available on the market. This design allows for extremely power-intensive space missions while requiring only minimal stowed volume during launch. The PowerCube is easily resettable, user-friendly, and readily available as a Commercial Off-The-Shelf (COTS) subsystem. Key features include a short delivery time of 12 months, an End-of-Life (EOL) power output of 100 W over a 5-year lifetime, and a compact stowed volume of 100x100x100 mm (1U). When deployed, it measures 110x110x190 mm. The array has a mass of 1.2 Kg and operates with a bus voltage of 14-28 V. It also features redundant actuation and is compliant with the CubeSat standard. The Dcubed Origami Solar Array is ITAR Free.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
