SWATH – Spiral Wrap Antenna Technology
Opterus Research and Development
SWATH is a patent-pending deployable solid surface parabolic dish antenna designed for high-frequency space communications, offering a stress-free deployed configuration and compact stowage.
Typed specifications3 values
Discloses 3 of 10 fields engineers filter by in this category (category median 3).
- Frequency range
- 100 000 MHz min · description
- Antenna type
- reflector (parabolic) Parabolic dish antenna, center-fed and offset-fed · datasheet p.1
- Fixed or deployable
- deployable SWATH Solid Surface Deployable Antenna · datasheet p.1
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier3 lines, in the manufacturer's own wording
- Operating frequencies
- Over 100 GHz
- Stowed volume (for <1m diameter)
- 1x1x1.5U
- Area weight
- Less than 300 gsm
About
SWATH (Spiral Wrap Antenna Technology) is a patent-pending deployable solid surface parabolic dish antenna. Unlike mesh systems, its solid surface technology allows it to operate at much higher frequencies, exceeding 100 GHz. The design ensures that the antenna is stress-free in its deployed configuration, eliminating the high tension loads typically required by mesh systems. SWATH is engineered for compact stowage, collapsing into a short, small-diameter cylinder. This cylinder features a central cavity specifically designed to house the feed system support structure and associated electronics. The antenna can be packaged into a volume as small as 1x1x1.5U for diameters less than 1 meter, and it boasts a low area weight of less than 300 gsm.
