TiNi Flat Pack FP50 Miniature Hold-Down Release Mechanism
Ensign-Bickford Aerospace & Defense (EBAD)
The TiNi Flat Pack FP50 is a miniature, non-pyrotechnic, and field-resettable hold-down release mechanism utilizing shape memory alloy for low-load applications.
Typed specifications5 values
Discloses 0 of 10 fields engineers filter by in this category (category median 2).
- Mass
- 33 g max · max · datasheet p.7
- Power consumption
- 1.25 W product page
- Operating temperature
- -65 °C product page
- Actuator
- -150 product page -150
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier13 lines, in the manufacturer's own wording
- Mass
- 1.17 oz (33 g) max
- Power
- 1.25 W @ .75 A
- Operational current
- .4 A to 1.5 A
- Resistance
- 3.3±.3 Ω @ 23°C
- Max release load
- 50 lbf (222.4 N)
- Proof load
- 100 lbf (444.8 N)
- Function time
- 130 mSec @ .5 A (23°C) typical
- Max torque
- 15 in-oz (106 N mm)
- Reusable
- By manual reset
- Life
- 50 cycles min
- Operating temperature
- -65°C to + 70°C
- Non-operational pre-actuation temperature
- -150°C to + 70°C
- Non-operational post-actuation temperature
- -150°C to + 150°C
About
The TiNi Flat Pack FP50 is a miniature hold-down release mechanism (HDRM) designed for various low-load applications such as solar arrays, antenna reflectors, instruments, doors, sensors, and booms. It operates using a Shape Memory Alloy (SMA) wire that, when heated, reverts to its original shape, causing actuation. Key features include field resettability, an auto shut-off switch, low height (<.25"), no debris generation, qualification to standard launch environments, range safety friendliness, and the use of space-rated materials. The device is constructed with an SMA wire threaded through a bell crank, which retains a trigger that keeps drive springs on a slider compressed. A smaller reset spring assists in the reset process. It is non-pyrotechnic and can be manually reset, with a minimum life of 50 cycles. It has an extensive operational temperature range.
