Deployers 3U
KOSMOLAB Launch Services
Deployers 3U provide transport and deployment of 3U-class CubeSats, compatible with various launch vehicles and customizable to specific requirements.
Key figurescomparable across the catalogue
- Mass
- 3.5 kg
- Largest dimension
- 457 mm
Normalised to common units so this product can be compared with others in its category. The supplier's own wording is below.
As published by the supplier
- Dimensions (L×W×H)
- 457 × 158 × 187 mm
- Mass
- 3.5 kg
- Max. satellite mass
- 6 kg
- Separation time
- <= 1 с
- Separation velocity
- 0.5 — 2.0 м/с
- Angular separation velocity
- <= 2 °/с
- Operating temperature
- −60°C to +60°C
- Payload
- 1 х CubeSat 3U
About
KosmoLab 3U Deployers are designed for the safe transport and deployment of 3U-class CubeSats. These deployers are compatible with a range of launch vehicles, including Angara, Soyuz/Fregat, PSLV, and Start-1M, offering versatility for various mission profiles. Customization options are available to match the specific requirements of your CubeSat, ensuring optimal integration and performance. The deployers are engineered for reliable operation, featuring a separation time of less than 1 second and a separation velocity ranging from 0.5 to 2.0 m/s. They can withstand operating temperatures from -60°C to +60°C, making them suitable for diverse space environments. The robust design accommodates a maximum satellite mass of 6 kg.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
