Compact 98cm dual-band (Ka and Ku) transmit/receive antenna system for economical VSAT deployment.
98cm Ka/Ku RxTx Class I Antenna System
Compact 98cm dual-band (Ka and Ku) transmit/receive antenna system for economical VSAT deployment.
Description
This is a small-aperture VSAT terminal antenna for cost-effective, high-performance service in both Ka-band and Ku-band. It provides fine azimuth and elevation adjustment for precise pointing and meets or exceeds Class I regulatory antenna-pattern requirements. It mounts directly with SpaceBridge's 3W/4W Ku- and Ka-band transceivers via a bracket to form a complete outdoor unit. Deployment options include a tri-mast mount (fits virtually any surface), 2x30m color-coded RG-6 coax cabling, and a 4'x4' non-penetrating roof mount. It targets enterprise/broadband VSAT, cellular backhaul, and mobility/UAV satcom applications needing a compact, economical, dual-band terminal antenna.
Specifications
| Effective aperture | 98 cm |
|---|---|
| Azimuth range | 360° continuous (±5° fine adjustment) |
| Elevation range | 5° - 90° continuous |
| Mast pipe interface diameter | 60.3 mm |
| Operating temperature | -50°C to +60°C |
| Frequency | Tx 28.00 – 30.00 GHz |
| Frequency (Rx) | Rx 17.80 – 20.20 GHz |
| Gain | Tx 47.2 dB @ 30.0 GHz |
| Gain (Rx) | Rx 44.0 dB @ 20.2 GHz |
| Gain variation | ±0.2 dB |
| VSWR | Tx 1.3:1 |
| VSWR (Rx) | Rx 1.3:1 |
| Isolation | Tx 90 dB |
| Isolation (Rx) | Rx 80 dB |
| Cross pol 1dB beamwidth | Tx 25 dB |
| Cross pol 1dB beamwidth (Rx) | Rx 22 dB |
