Precision

• GSDNative 0.6 m PAN at reference orbit; 0.3 m effective pixel sampling (4 half-pixel shifted PAN channels); 1.2 m multispectral
• Swath9.7 km at reference orbit
• Spectral bandsPAN 450-700 nm; 6 multispectral bands 420-900 nm, up to 4 simultaneous

Very high resolution optical Earth observation satellite for mapping, surveillance and security applications.

TrueColour

• GSD5 m
• Swath120 km
• Spectral bandsMultispectral, 9 bands 433-907 nm

Medium resolution, wide swath multispectral Earth observation satellite built on the Carbonite platform.

CarbSAR

• GSD0.5 m
• Swath4 km
• Spectral bandsX-Band

Small satellite with deployable X-band Synthetic Aperture Radar payload for day/night, all-weather imaging.

DarkCarb

• GSD4 m
• Swath4 km
• Spectral bandsMWIR (3.7-4.95 µm)

High resolution mid-wave infrared (MWIR) imaging satellite for day and night Earth observation.

Carbonite

• GSD1 m
• Swath5.5 km
• Spectral bandsOptical (RGB Bayer)

Low-cost 1m GSD optical Earth observation satellite providing HD colour video from space.

GNSS-RO Atmospheric and Ionospheric Data

• InstrumentPyxis GNSS-RO receiver (4th generation, NASA-heritage, rad-hard)
• Signal sourcesGPS, GLONASS, Galileo, BeiDou
• SNR1,500 V/V (60 dB-Hz) — 7.5× higher than competing instruments

High-resolution GNSS Radio Occultation data from LEO constellation delivering global atmospheric profiles at 100m vertical resolution with SNR…

Puli Lunar Water Snooper (PLWS)

• Instrument typeMiniature neutron spectrometer
• MeasurementAlbedo neutron count rates (subsurface hydrogen / water ice proxy)
• Mission heritageIM-2 (Intuitive Machines), launched February 2025, Micro Nova Hopper

NASA-prize-winning miniature neutron spectrometer for mapping water ice in lunar south polar soil, flight-proven on Intuitive Machines' IM-2…

Quub Earth Observation Constellation

• PlatformPocketQube-class microsatellites
• ApplicationsWater resources, forests, crops, air quality monitoring
• Ground systemsAI-powered imagery processing

PocketQube constellation delivering high-frequency Earth observation imagery for water, agriculture, disaster response, and air quality monitoring.

RCMOS Space Camera

• Sensor typeCMOS, global shutter, progressive scan
• Spectral range0.3–1.1 µm (visible + NIR)
• VariantsMono and colour

Space-qualified CMOS camera for LEO CubeSat integration, combining compact form factor with high sensitivity across 0.3–1.1 µm.

Ninox eSWIR 640 Space Camera

• Spectral rangeExtended SWIR (eSWIR), beyond 2 µm
• Format640 pixels
• ApplicationsHyperspectral imaging, night-time surveillance, thermal and mineral remote sensing

Extended-SWIR 640-pixel space camera for hyperspectral, thermal, and night-time remote sensing payloads on LEO CubeSats.

Eagle 47-10 Space Camera

• SensorBack-illuminated 1MP CCD (Teledyne e2v)
• Pixel size13 µm x 13 µm
• Peak QE>90% @ 525 nm; 50% @ 380 nm and 720 nm

Deep-cooled back-illuminated 1MP CCD space camera with 7-year vacuum guarantee and >90% QE at 525 nm for LEO…

SpectraLoc Payload

• CapabilitiesPassive emitter detection, classification, direction-finding, geolocation
• Detection rangeExtended line-of-sight
• Platform compatibilityFixed-wing drones, quadcopters, VTOL platforms (small UAVs)

Compact airborne RF payload for passive threat detection, direction-finding, and geolocation, built for small UAV integration.

Scanway Optical Payload (SOP)

• SOP NANO aperture20-100 mm
• SOP NANO ground sample distance<= 5 m/pixel
• SOP MICRO aperture120-450 mm

Satellite telescope/camera line for remote sensing, offered in NANO and MICRO configurations.

Scanway Camera System (SCS)

• Configuration variantsSingleCam, MultiCam, SmartCam
• TRL9 (validated via YPSat mission)
• ApplicationsSpacecraft monitoring, docking, deployment/separation observation

Modular in-orbit vision system for spacecraft monitoring, docking, and deployment/separation observation.

Polaris 4-channel AIS Receiver

Self-contained 4-channel Satellite-AIS receiver, flight-proven second-generation SDR platform.

Polaris ADS-B Receiver

Self-contained SDR receiver for 1090 MHz ADS-B, flight-proven second-generation SDR platform.

Polaris LoRa Receiver

Self-contained SDR receiver for 868 MHz ISM LoRa, flight-proven second-generation SDR platform.

AirSAR-Alpha-X

Multi-channel X-band SAR payload for airborne platforms, delivering ultra high-resolution imagery at 0.3-0.5 m resolution.
