Software & Services

Ubik Systems Engineering Platform

Charter Space

Commercial plan$99/month or $1,000/year
GovCloud plan$499/month or $5,000/year
SecuritySOC 2 certified, CMMC Level 1 compliant

Browser-based systems engineering and mission-planning platform — requirements management, model-based systems engineering, test tracking, insurance quoting integration.

Ground Segment

Tracker 6000 X/C Band Tracking Antenna

CM Technology (CMT)

FrequencyX-band / C-band
ApplicationLEO satellite tracking, teleport gateway operations
Network40+ CMT teleport locations worldwide

X/C-band LEO satellite tracking antenna system deployed across CMT's global teleport network.

Ground Stations

Tracker 4300 L/S/C Band Tracker

CM Technology (CMT)

BandsL/S/C
PedestalSimplified design
Wind load restrictionsNone

Multi-band L/S/C tracker with simplified pedestal and no wind load restrictions — designed for Earth-imaging satellite ground segment.

Ground Stations

3.7m Dual Pol Full Ka Band Tracker

CM Technology (CMT)

Frequency3.5GHz Tx/Rx
BUC4 per polarization
AmplifierUp to dual 500W Ka TWTA

High-performance dual-polarization Ka-band tracking antenna for smallsat communications — unlimited azimuth rotation, dual 500W Ka TWTA capability.

Ground Stations

Gateway 3.7m S Band Tracker

CM Technology (CMT)

BandS (X/S available)
Lead time~20 weeks
Base modelST144

3.7m S-band gateway tracking antenna delivered to Europe for IoT applications — X/S configurations available, ~20-week lead time.

Ground Stations

Gateway 2.4m Ka Tracker

CM Technology (CMT)

BandKa
M&CSNMP-based TLE
Target platformsLEO/MEO cube/nano/small satellites

2.4m Ka-band gateway tracking antenna for LEO/MEO cube/nano/small-sat IoT applications — SNMP-based TLE monitoring and control, ROI under…

Chemical Propulsion

CHIPS CubeSat High Impulse Propulsion System

CU Aerospace

Propellant optionsR236fa and R134a (range-safety approved)
CHIPS-180 size0.54U
CHIPS-180 total impulse180 N-s

Miniaturized propulsion combining main thruster with 3-axis attitude control — non-toxic self-pressurizing propellants, 120M+ valve actuations, 0.54U CHIPS-180…

Electric Propulsion

FPPT Fiber-Fed Pulsed Plasma Thruster

CU Aerospace

Pulse duration10 microseconds
Specific impulse>3,500 s
Thrust vectoring range±5° (pitch/yaw)

High-Isp electric propulsion ablating spooled PTFE fiber via short pulses — >3,500s Isp, no pressurized tank, scales 0.7L-53L,…

Chemical Propulsion

MPUC Monopropellant Propulsion Unit for CubeSats

CU Aerospace

PropellantCMP-X (ethanol/hydrogen peroxide)
Flame temperature~900°C
Demonstrated Isp178 s at 230 mN thrust

High-thrust monopropellant propulsion using proprietary CMP-X ethanol/hydrogen-peroxide blend — safer, lower-cost alternative to hydrazine, >2,000 Ns total impulse.

Test Equipment & EGSE

P.R.O.B.E. 1 Stratospheric Balloon Test Mission

Delta Space Leonis

Mission typeStratospheric balloon test campaign
Launch locationPo Valley, northern Italy
PartnerToSpace (India)

Stratospheric-balloon test campaign validating satellite subsystems ahead of orbital launch — in-orbit-demonstration validation service, flown over northern Italy.

SmallSat Platforms

PocketQube Satellite Platform

Delta Space Leonis

Mass250 g
Dimensions5x5x5 cm

Miniaturized satellite platform (PocketQube class) using high-performance solar cells and compact antennas — 250g, 5x5x5cm, for low-cost orbit…

Communications

LEONIS Constellation IoT Connectivity

Delta Space Leonis

ApplicationsEnergy monitoring, infrastructure monitoring, smart farming, logistics/tracking
CoverageIndependent of cellular/internet coverage

Satellite constellation providing IoT sensor connectivity beyond terrestrial networks — energy, infrastructure, agriculture, and logistics applications.

Payloads & Instruments

Galileo-1 VSPU (Visual Sensing and Processing Unit)

Diffraqtion

Detection distance20x further than current CMOS/CCD sensors
Processing speed1000x faster than conventional GPU/VPU + CMOS
Energy efficiency1000x more efficient than current GPU/VPUs

Award-winning quantum-sensing camera with the fastest onboard vision AI — 20x further object detection than CMOS/CCD, 1000x faster…

Software & Services

PocketQube Mission Support Services

DIYSATELLITE

PricingPocketQube missions starting from USD 15,000
MilestoneFirst commercial customer deployment campaign scheduled mid-2026

End-to-end PocketQube mission support — design, integration, deployer validation, and launch support for universities, startups, and technical teams,…

Chemical Propulsion

ATOM Monopropellant Thruster

DREAM Aerospace

ThrustStarting from 1N
Compatible platforms1U to 26U+ CubeSats
PropellantEco-friendly, nontoxic monopropellant

Next-generation monopropellant thruster using eco-friendly, nontoxic propellant — starting from 1N thrust, for 1U to 26U+ CubeSats, 30x…

Chemical Propulsion

CubeHood Propulsion Module

DREAM Aerospace

Compatible platforms1U to 26U+ CubeSats
AssemblyReady-to-use, no additional assembly required

All-in-one, ready-to-use propulsion module integrating with the ATOM thruster — combines fuel tanks and thrust control for CubeSat…

Chemical Propulsion

GEM3 Green Electric Monopropellant

Digital Solid State Propulsion

Hazard class1.4C
100g sample pricing$100
1kg pricing$525

HAN-based liquid monopropellant, electrically ignitable or catalyst-bed ignitable — comparable to AF-M315E with slightly higher performance and faster…

Chemical Propulsion

AF-M315E (ASCENT) Green Monopropellant

Digital Solid State Propulsion

Hazard class1.4C
10lb (1gal) pricing$3,850
50lb (5gal) pricing$16,500

Green (nontoxic) monopropellant developed by AFRL and licensed to DSSP — higher-performance, less-toxic alternative to hydrazine.
